PS200A/300A/400A/600A/800A Automatic Series Self-priming Pump

Application &Feature

Waltek Automatic PS series Self priming water pumps are for clean water without abrasive particles and the fluids which are not chemically aggressive to the pump componets.

There are used for domostic applicance and automatic distribution of water form surge tanks .for

watering gardens and for boosting insufficent mains water pressure.

Working Conditions

•  Suction lift up to 9m.
•  Liquid temperature up to +40℃.
•  Ambient temperature up to +40℃.
•  Max. Working pressure: 5 bar.
• Trans medium's PH:6.5~8.5.

Motor

•  Single phase two-pole induction motor.
•  220V/50Hz  220V/60Hz 100V/60Hz
•  Thermal Protector,continuous duty.
• Insulation class:B
•  Protection: IP 44.

SPECIFICATION DATA:
